구 분

(kgf-m)

(kgf-m)

( ° )

d

D

L

L₁

C

L₂

A×B

탭

(kg)

KW-00

0.8

1.6

30

6

12

75

25

25

18.5

-

-

0.045

KW-08

1.5

3.2

30

8

16

86

28

30

19

-

-

0.090

SAW-10

KW-10

3.0

7.5

30

10

20

102

34

34

24

3 × 11.5

M 5

0.160

SAW-12

KW-12

4.5

12.0

30

12

24

125

42

41

29

4 × 12.0

M 5

0.300

SAW-14

KW-14

7.0

17.0

30

14

28

143

47

49

32

5 × 16.5

M 6

0.500

SAW-16

KW-16

10.0

25.0

30

16

32

158

52

54

35

5 × 18.5

M 6

0.650

SAW-18

KW-18

13.0

32.0

30

18

36

180

60

60

39

6 × 21.0

M 6

0.950

SAW-20

KW-20

18.0

45.0

30

20

40

188

62

64

40

6 × 23.0

M 6

1.200

SAW-22

KW-22

24.0

60.0

30

22

44

200

65

70

42

6 × 25.0

M 6

1.500

SAW-25

KW-25

30.0

80.0

30

25

50

220

70

80

43

8 × 29.0

M 8

2.200

SAW-30

KW-30

45.0

115.0

30

30

60

275

89

97

54

8 × 34.0

M 8

4.000

SAW-35

KW-35

55.0

180.0

30

35

70

310

100

110

58

10 × 40.0

M 8

6.050

SAW-40

KW-40

85.0

250.0

30

40

80

350

114

122

67

12 × 46.0

M 10

9.500

SAW-45

KW-45

125.0

350.0

30

45

90

390

125

140

74

-

-

12.000

SAW-50

KW-50

180.0

490.0

30

50

100

426

135

156

80

-

-

17.600

SAW-60

KW-60

280.0

650.0

30

60

120

485

150

185

85

-

-

30.000
