구 분

d

전장

MIN
작동
거리

E

스플라인규격 S

G

LC

D

A

H

J

MIN

MAX

-

-

-

-

65

involute 대경 =10 m = 0.75 z = 11

20

36

-

37

65

-

8

140

290

+30

65

involute 대경 =10 m = 0.75 z = 11

20

-

16

37

65

30

SBL-10

10

160

320

+30

65

involute 대경 =12 m = 1.0 z = 10

20

42

19

37

65

30

SBL-12

12

180

360

+30

88

16 × 13 × 3.5 - 6

25

52

23

56

89

30

SBL-14

14

190

410

+30

87

16 × 13 × 3.5 - 6

25

59

26

54

89

30

SBL-16

16

220

440

+30

115

20 × 16 × 4 - 6

30

74

30

75

120

30

SBL-18

18

240

520

+30

115

20 × 16 × 4 - 6

30

81

33

70

120

30

SBL-20

20

250

540

+30

118

22 × 16 × 5 - 6

35

87

36

73

125

30

SBL-22

22

270

570

+30

115

25 × 21 × 5 - 6

35

94

40

68

125

30

SBL-25

25

310

630

+50

133

28 × 23 × 6 - 6

45

105

44

83

145

50

SBL-30

30

350

720

+50

145

32 × 26 × 6 - 6

45

122

51

85

160

50

SBL-35

35

380

900

+50

150

38 × 32 × 8 - 6

50

140

59

85

170

50

SBL-40

40

410

1000

+50

165

42 × 36 × 8 - 6

60

157

67

95

190

50

SBL-45

45

450

1150

+50

180

45 × 41 × 8 - 6

70

176

75

105

210

50

SBL-50

50

490

1200

+50

200

52 × 46 × 9 - 6

80

191

83

115

230

50
